Ligier JS1

Ligier JS1
ManufacturerLigier
CountryFrance
Production Started1969
Production Stopped1970
Body StyleCoupe

The Ligier JS1 was a French sports car introduced in 1969, designed by Guy Ligier, a former racing driver, with an eye toward competing in endurance racing. Named in tribute to Ligier’s friend and fellow racer Jo Schlesser (hence “JS”), who died tragically in a crash, the JS1 marked Ligier’s entry into the automotive and racing industries. The car was created with a focus on lightweight design, high performance, and handling, setting the foundation for Ligier’s later success in motorsport.

The JS1 featured a mid-mounted Ford Cosworth 1.6-liter four-cylinder engine in its earliest versions, with some models later upgraded to a more powerful 2.0-liter V6 engine. The engines produced between 120 and 160 horsepower, which, combined with the car’s lightweight fiberglass body and tubular steel chassis, allowed it to reach competitive speeds and exhibit nimble handling on the track. The JS1 was paired with a 5-speed manual transmission, providing drivers with control and responsiveness ideal for endurance racing.

Designed for both style and function, the JS1 had a low, aerodynamic profile and a compact build that reduced drag and improved stability. The car competed in notable events like the Tour de France Automobile and the 24 Hours of Le Mans, but unfortunately, it suffered mechanical issues in many races, preventing it from achieving notable finishes. Despite this, the JS1 was praised for its innovative design and solidified Ligier’s reputation in motorsports, leading to the development of future models.

The Ligier JS1 remains an important car in the history of French motorsport, both as Ligier’s first venture into racing cars and as a rare collector’s item appreciated for its sleek design and significance in the evolution of Ligier’s racing legacy.

Vehicle

Production Numbers3
Number of Doors2
Number of Seats2

Engine

Engine ManufacturerFord
EngineV6
Engine LocationMid
Engine Displacement2548 cc
ValvetrainOHV
Valves per Cylinder2
Bore90 mm
Stroke66.8 mm
Cooling SystemWater
Charging System6V
Fuel TypePetrol
Fuel SystemCarburator
AspirationNormal

Performance

Top Speed155 mph
Power158 / 215 / 212 @ 6500 rpm

Steering, Transmission & Suspension

DrivetrainRear
TransmissionM5
SteeringRack and Pinion
Front SuspensionLeaf Spring
Rear SuspensionLeaf Spring
Front BrakesMechanical Braking
Rear BrakesMechanical Braking
ChassisBody-on-Frame

Dimensions

Weight790 kg
Length3950 mm
Width1720 mm
Height1150 mm
Wheelbase2350 mm
