Abarth 1000 Zagato

Abarth 1000 Zagato
ManufacturerAbarth
CountryItaly
Production Started1960
Production Stopped1960
Body StyleCoupe

The Abarth 1000 Zagato is a remarkable blend of Italian performance engineering and design, a car that encapsulates the racing spirit of the 1960s. Created by pairing Abarth’s tuning expertise with the renowned design house Zagato, this model took the foundations of the Fiat 600 and elevated it to new levels of speed and style. The car’s name, “1000,” refers to the 1,000cc engine that Abarth developed, which was a heavily modified and more powerful version of Fiat’s original engine. This high-performance engine was tuned to deliver impressive power for a car of its class, allowing it to excel on both the racetrack and open roads.

Zagato’s contribution was in crafting the Abarth 1000’s lightweight, aerodynamic body, which included the signature “double bubble” roof—a design feature intended to reduce drag while providing extra headroom and structural rigidity. The sleek lines, rounded front, and smooth, flowing contours were as functional as they were attractive, optimized to enhance the car’s performance at high speeds. The car’s low stance, flared wheel arches, and distinctive Zagato styling gave it an aggressive, sporty look, which made it instantly recognizable and iconic.

The Abarth 1000 Zagato quickly made a name for itself in European motorsports, particularly in endurance races and hill climbs where its agility, light weight, and power-to-weight ratio made it a strong competitor. The car’s performance on the racing circuit solidified Abarth’s reputation for transforming small-displacement cars into serious contenders, and its striking design helped cement its status as a collector’s item.

Today, the Abarth 1000 Zagato is celebrated as a classic among vintage car enthusiasts. Its combination of engineering, design, and racing success has made it a highly sought-after model, appreciated both for its aesthetics and its historical importance. The 1000 Zagato remains a symbol of 1960s Italian innovation and a testament to Abarth and Zagato’s commitment to performance and style.

Vehicle

Production Numbers0
Number of Doors2
Number of Seats2

Engine

Engine ManufacturerFiat
EngineInline 4
Engine LocationRear
Engine Displacement982 cc
ValvetrainDOHC
Valves per Cylinder1
Bore65 mm
Stroke74 mm
Cooling SystemWater
Charging System6V
Fuel TypePetrol
Fuel SystemCarburator
AspirationNormal

Performance

Top Speed124 mph
Power67 / 91 / 90 @ 7100 rpm
Torque104 / 77@t 5500 rpm

Steering, Transmission & Suspension

DrivetrainRear
TransmissionM4
SteeringRack and Pinion
Front SuspensionLeaf Spring
Rear SuspensionLeaf Spring
Front BrakesMechanical Braking
Rear BrakesMechanical Braking
ChassisBody-on-Frame

Dimensions

Weight570 kg
Length3590 mm
Width1390 mm
Height1170 mm
Wheelbase2000 mm
